Specification

Ocean Freight

Dry/Steel Internal Dimension (mm) Weight (kg) Volume (m3)
Type/Size Length Width Height Max. Gross (kg) Tare Max. Payload Capacity to load line
20' std
20' x 8' x 8' 6"
5,896 2,350 2,385 27,000 2,150 24,850 33
40' std
40' x 8 x8' 6"
12,035 2,350 2,393 32,500 3,700 28,800 67
40' high cube
40' x 8' x 9' 6"
12,035 2,350 2,697 34,000 3,800 30,200 76


Open Top Internal Dimension (mm) Weight (kg) Volume (m3)
Type/Size Length Width Height Max. Gross (kg) Tare Max. Payload Capacity to load line
20' open top
20' x 8' x 8' 6"
5,919 2,340 - 30,480 2,300 28,180 32
40' open top
40' x 8' x 8' 6"
12,043 2,338 - 30,480 3,800 26,680 64


Flat Rack/Steel Internal Dimension (mm) Weight (kg)
Type/Size Length Width Height Max. Gross (kg) Tare Max. Payload
20' collapsible
20'x 8'x 8' 6"
5,966 2,418 2,286 30,480 2,970 27,510
20' fixed-corner
20' x 8' x 8' 6"
5,935 2,398 2,327 24,000 2,560 21,400
40' fixed-corner
40' x 8' x 8' 6"
12,080 2,438 2,103 30,480 5,480 25,000


Reefer/Aluminium Internal Dimension (mm) Weight (kg) Volume (m3)
Type/Size Length Width Height Max. Gross (kg) Tare Max. Payload Capacity to load line
20' std
20' x 8' x 8' 6"
5,430 2,286 2,155 27,000 2,750 24,250 26.8
40' std
40' x 8' x 8' 6"
11,577 2,294 2,110 32,500 3,900 28,600 56.1
40' high cube
40' x 8' x 9' 6"
11,577 2,294 2,400 34,000 4,600 29,400 67.5
